High-efficiency automated equipment for synchronized dual-head stranding of preformed wires, metal fittings, and aluminum alloy wires with precision angle control and industrial-grade reliability.
The Double-Head Helical Stranding Machine is a high-efficiency device specifically designed for the stranding of preformed wires, metal fittings, aluminum alloy wires, and other wire products. Featuring synchronized dual-head stranding, automatic reset positioning, and precise angle control, this machine significantly enhances production efficiency and precision.
Equipped with an intelligent control system, the machine automates the entire process from forward/reverse stranding switch, tension release, automatic compression positioning, to safety stop, offering high precision and efficiency in wire processing. Widely used in industries such as electric power, telecommunications, hardware processing, and metal materials manufacturing.
PLC system ensures stranding accuracy within ±1° for consistent quality
Simultaneous dual-head operation with independent drive systems
Electric + pneumatic combination for automatic clamping and release
Infrared safety light curtains and emergency stop functions
| Parameter | Specification |
|---|---|
| Control System | Weinview vs. Mitsubishi |
| Stranding Mode | Single-head/Dual-head switchable |
| Angle Control Precision | ±1° |
| Stranding Speed | 0-1 turn/second |
| Air Pressure Requirement | 0.5-0.6 MPa |
| Power Supply | AC 380V / 50Hz |
| Operating Mode | Automatic/Manual dual modes |
| Cycle Time | 3-6 seconds per cycle (adjustable) |
| Safety Features | Infrared safety light curtains + Emergency stop function |
| Material Compatibility | Aluminum alloy wire, copper wire, preformed strands, and other metal wires |
| Tension System | Electric + Pneumatic combination control |
| Drive System | Dual independent motors |
Versatile solutions for diverse industrial applications across multiple sectors
Manufacturing of preformed armor rods, tension clamps, and suspension clamps for overhead power lines. Ensures consistent quality for critical electrical infrastructure components.
Production of communication line clamps and ADSS fiber optic preformed armor rods. Maintains precision for reliable network infrastructure.
Fabrication of electrified railway contact network clamps. Withstands high-vibration environments while maintaining structural integrity.
General metal wire processing for various hardware components. Adaptable to different product specifications and batch requirements.
Advanced PLC system independently controls forward, reverse, and reset angles with ±1° precision, ensuring consistent stranding quality across all production batches.
Combined electrical and pneumatic control system enables automatic material clamping, loosening, and resetting operations for seamless production flow.
User-friendly touchscreen HMI allows real-time parameter adjustment and monitoring, simplifying operation while maintaining precise control.
Flexible single-head/dual-head mode switching accommodates various product specifications and production requirements.
Infrared safety light curtains and emergency stop functions ensure operator safety during all machine operations.
Robust steel frame and high-quality components guarantee reliable performance under continuous industrial operation conditions.
Our team provides fast technical support, detailed product information, and customized machine solutions for your production needs.
